LFA SC 2.5 BL – Medium Static Compactor – Bin Lift

Description

The LFA SC 2.5 BL is our medium static compactor with an integrated bin lift system. The 1400x1430mm feeding opening and 1.88m³ charge box is great for use with the bin tipper. By using the LFA SC 2.5 BL, it ensures that charges are correct for disposal instead of being overcharged for under capacity skips and bins. Boasting a high 30t compaction force the LFA SC 2.5 BL is capable of achieving payloads of up to 10t into a 35-yard RoRo skip. The straight push ram is a low maintenance system which has a fast cycle time of 54 seconds meaning it can compact up to 125m³ of waste per hour. Static compactors are most commonly used for dry general waste, but it can be used on lots of different applications where compaction is required.

The integrated bin lift is great for reducing manual labour and to easily feed the compactor. As standard it is able to lift 1100L wheelie bins via its pintel up to 450kg. The bin lift can be specified with an all-round safety cage.

Compactor Measurements
Width
3963mm
Height
1300mm
Depth
2220mm
Load Weight
8000kg (avg.)
Payment Options
Purchase
Lease
Availability
New
Refurbished

Product Details

Product Dimensions
Overall Width3963mm
Overall Height1300mm
Overall Depth2220mm
Overall Weight~3300kg
Feed Opening Width1400mm
Feed Opening Depth1430mm
Technical Specification
Compaction Force 30T
Motor 7.5kW
Cycle Time 54 Seconds
Ram Penetration 350mm
Charge Box Depth 940mm
Charge Box Volume 1.88m³
Max Volume Displacement Per Hour 125m³
Electricity Supply 3 Phase, 415V, 32A

The compactor can be specified with a 75% and 100% full light and we can fabricate the feed hopper to hit your needs. A cage can be attached to it for extra precaution. To destroy material, we can supply a pre-crush variant to destroy products or force liquids out of bottles/cans. For further customisation, contact us and we will try to meet all requirements.

Typically, the minimum amount of waste per week to gain a cost saving would be either:

  • 1100ltr wheelie bins – Fifteen GW (General waste)
  • FEL (Front end loader) skip(s) – Three GW
  • REL (Rear end loader) skip(s) – Two GW

Features

  • E-stops
  • Skip clamps
  • ¾ full indicator
  • Automatic cycle
  • Integrated bin lift system
  • Simple, easy to operate controls
  • Hydraulic pack separate from waste
  • Powerful 30 tonne compaction force
  • Rated IP65 so safe to be sited inside or outside
  • Low maintenance straight ram compaction method



Benefits

  • Helps prevent fly tipping
  • Keeps the yard much tidier
  • Reduces waste disposal costs
  • Reduces contractor traffic on site
  • More environmentally friendly
  • Fast interchange of skips so minimal down time
  • No longer being charged for air voids in skips/bins
  • Reduces carbon footprint and complies with ISO 14001

The LFA SC 2.5 BL is extremely easy to use and requires very little manual work.



Step 1 – Setup

When installing, the LFA SC 2.5 BL must be bolted to the floor by one of our engineers. Once installed, the contractor will supply and attach an enclosed 35yd RoRo hook lift skip to it via the compactor’s clamps.



Step 2 – Feeding

Wheel the bins full of waste up to the compactor. The operator holds the bin lift and ‘up’ buttons on the control panel and the integrated bin lift will start lifting the bin up via its pintels, the waste from the bin will then be tipped into the charge box. On the control panel the operator will then hold down the bin lift and ‘down’ buttons at the same time to return the bin to the floor. Press the green ‘go’ button to start the compaction cycle. The straight ram will then compact the waste from the charge box into the attached skip. In its standard setup this will cycle 3 times, but it can be configured to run more/less or on a timer.



Step 3 – When is the skip full?

The compactor has an indicator to notify the operator when the skip is ¾ full. Once this illuminates, the operator can calculate when it will be full and when the skip needs to be collected by the waste contractor.



Step 4 – Waste removal

The contractor will arrive on site with a hook lift vehicle and an empty skip, they will set down the empty skip to one side and then start inserting pinning bars to stop the compacted waste from ejecting out of the skip. They will loosen the clamps and detach the skip from the compactor, they then pull the skip away slightly and attach a cover over the opening on the skip to ensure no loose debris falls out in transportation. The full skip is then moved out of the way and set down, the empty skip is then picked back up, moved into place and clamped to the SC 2.5 BL ready for compaction. The contractor then picks up the full skip and takes it away.



As simple as that! It probably takes longer to read the operation than to implement it. As part of the package, one of our trusty engineers will come to site and show the team how to operate it in person. Training certification can be supplied if required.



*Note – Refurbished models may vary in its operation slightly, but the principle will remain very similar.
